Tamiya Fun Craft Series No.260 Universal Gearbox 2 japan NEW

[Gearbox with two intersecting shafts at right angles.] This is an assembled gearbox with two shafts arranged at right angles, each of which can take out motion. Three different gear ratios can be selected for each gearbox, and the fixing mounts are removable. By changing the mounting position, four different directions of the output shaft can be selected. The main body is made of clear parts that clearly show the internal mechanism. A convenient crank plate is also included for varying the movement. [Basic Specifications] Overall length, width, height, and width of the output shaft are 63mm, 29.8mm, 27.8mm, and 13.4mm, respectively. Includes 130 type motor. Gear ratios 102.4:1, 273.1:1, 728.2:1 (for 3mm hex shaft), 8.5:1, 22.8:1, 60.7:1 (for 2mm shaft). Includes crank plates for 3mm hex shafts and 2mm shafts, as well as mounting screws and nuts. Four different output shaft orientations can be selected by changing the mounting position of the mount. Both 3mm hex shaft and 2mm shaft are available in 3 different gear ratios. Information is current as of 09/03/2024. Product name, price, release date, and specifications are subject to change without notice. (From Tamiya website)
